Groin: HARTFORD
Extra large span between columns +One piece fabricated oversized column construction combined with 1200x1135mm, bam supporting face assure the best possible structural rigidity. Oil and fluid separated structure +Oil and fluid separated structure effectively extends the service life of cutting fluid, lower production cost and meet environmental protection requirements which is not found on some of competitors' models. SRG65 high rigidity roller-type blocks +Y-axis is equipped with the latest SRG65 high rigidity roller-type blocks with retainer. It increases movement rigidity and stability, eliminates moving friction between rollers, increases sensitivity and roller service life. |
W-axis with four clamping devices +Four clamping devices are provided at both side of W-axis to avoid W-axis slipping down at any position throughout its entire stroke, eliminating affection on machining accuracy. Double hydraulic accumulators W-axis employs double hydraulic accumulators for counter-balancing, minimizing unparalleled torque while assuring the best travel accuracy. |
