Straight Side Double Crank Power Presses
STD series is designed for the application of high precision, heavy metal stampings works, such as motorcycle and bicycle parts, and home appliance components. Automation provisions, STD can be easily upgraded for progressive robotic or mechanical transfer system.
- Wide bed for large tools.
- Straight slide steel frame with superior rigidity in one piece or with separated members like the crown, bed, uprights connected by four tie rods pre-stressed hydraulically with nuts.
- Low-inertia, fast-response, and air-cooled separate clutch & brake.
- High-performance hydraulic overload protection.
- Double-geared and twin-end driven gear arrangements.
- Extra-long, 8-face slide gibbings.
- Provision for the automatic feed system and the quick die change system.
