Straight side 4-point link drive eccentric gear press
Straight side 4-point link drive eccentric gear press 400~2400 ton
SL4 model mainly features its extra-large bolster, utilizing 4 point pressure from slide to achieve  , cutting-off, bending, forming and drawing process for automotive sheet metal. This press best suits for automotive industry, usually applied in below range:
- Tooling with Front-Rear dimension longer than 2000 mm.
- Slide encounters extra off-center loading in Front-Rear dimension.
Body sheet metal processed in tandem press line, such as car ceiling, chassis, door, hood, etc.
- Long stroke
- Large working area
- Ultra rigid frame
- High performance clutch and brake
- High efficiency hydraulic overload protection device
- Slide eight point gib offers high precision and resistance to off-center loading.
- Facilitate integration with automated feeding system and quick die change system.
- Slow drawing process could effectively prevent sheet metal break out
- Reduce die cushion and tooling vibration, and prolong die life.
- Reduce noise during stamping process
- Reduce vibration, and prolong usage life of electrical and other peripheral equipment.
- The production rate could be largely elevated under same drawing velocity.
