CNC HYDRAULIC PRESS BRAKE YCN/DA-66T SERIES

Yeh Chiun press brake company develops and produces press brake machines with a reputation for superior quality and dependable services. The product lines contain CNC hydraulic press brake, NC hydraulic press brakes and universal hydraulic press brake. To fulfill the goal of producing high quality press brakes applied to machine tools at resonable prices, the company employs the experienced staff of engineers conducting research and development in new areas of press brake machine, as well as ongoing improvement programs for current hydraulic press brakes. Yeh Chiun has ISO-9001 quality assurance system certified also certified with CE machinery directiveand EMC compliance. we can satisfy customer's requirements. Click images below to learn more details and specifications or contact us for more information.

CNC/DA-66T System Introduction

DA-66T offers 2D programming which includes automatic bend sequence calculation and collision detection functions. Full 3D machine set-up with multiple tool stations giving true feedback on the product feasibility and handling. The touch screen gives access to the proven Delem user-interface and enables direct navigation between programming and production. Functions are directly located where you need them, offering optimized ergonomics throughout the application.

Standard:

1. 2D graphical touch screen.
2. 3D visualization in simulation and production.
3. 17" color LCD display. (TFT)
4. Standard Windows functions. User specific applications support.
5. USB keyboard, mouse and flash memory drive.
6. Emergency stop device.
7. German HOERBIGER hydraulic circuit.
8. Equipped with European optical scales.
9. Precision ball screw lead, linear slide way and AC servo motor for X axis.
10. Bearing-type guideway system.

Main Function:

1. Alphanumeric product naming.
2. Automatic bending sequences calculation and setting.
3. Multi-aspect programming, graphics programming, data programming and one page programming table.
4. Millimetres/Inches, KN/Ton and languages selection.
5. Programmable material properties and axes speed.
6. Bend sequences and real-scale tooling visualization while bending.
7. Computed functions include tooling safety zones, press force, crowning adjustment, developed length, axes position, operation modes and etc.
8. Step repeat up to 99 (maximum).
9. Error messaging system.
10. Hand-wheel movement of all axes.
