NC HYDRAULIC PRESS BRAKE YCN/NC-05 SERIES

Yeh Chiun press brake company develops and produces press brake machines with a reputation for superior quality and dependable services. The product lines contain CNC hydraulic press brake, NC hydraulic press brakes and universal hydraulic press brake. To fulfill the goal of producing high quality press brakes applied to machine tools at resonable prices, the company employs the experienced staff of engineers conducting research and development in new areas of press brake machine, as well as ongoing improvement programs for current hydraulic press brakes. Yeh Chiun has ISO-9001 quality assurance system certified also certified with CE machinery directiveand EMC compliance. we can satisfy customer's requirements. Click images below to learn more details and specifications or contact us for more information.

NC-05 System Functions

1. Adopt AC servo motor. Free of carbon brush and maintenance.
2. Speed of back gauge: 1000 rpm.
3. Preset Unit: 0.01mm.
4. Accuracy of back gauge(X axis): 0.01 mm
5. (G point of Servo motor is taken as the basis point).
6. The max. number of drawing number to be memorized is 156.
7. Each drawing No. offers 16 operations.
8. The range of preset workpieces is 99999; machine automatically stops when the whole processing completes
9. Control Function: Preset of modification of size, manual / semiautomatic / fully automatic / limit detection operation.
10. Manual input is simple and can be stored.
11. The controller is free from electromagnetic interference.
