 2 Speed ZF Gear Box
 CT-50 Spindle & Tool Changer
 Thru Spindle Coolant – 300 PSI
 Extra Coolant System, 105 Gallon, w/paper filter (21gal/min)
 4th Axis Cable Pre-wiring
 10.4" LCD Color Monitor
 Coolant system (540L)
 32 Tools ATC
 2 Screw type chip conveyors
 Chain type chip conveyor
 Oil coolant thru ballscrew & spindle system
 Fanuc function: AICC II, DATA SERVO W/ ETHERNET AND 1GB CF CARD, MANUAL GUIDE i, JERK CONTROL, HELICAL INTERPOLATION, HIGH SPEED SKIP, PRPGRAM STORAGE LENGTH 1280M.
FEATURES
 The machine base, columns, cross beam, work table, slide ways, head and all cast parts are of top grade Meehanite Cast Iron.
 X and Y axis with high precision heavy duty LM guide ways.
 Z axis with a tough cast iron box way construction.
 The Z axis is balanced with Nitrogen in conjunction with dual pneumatic cylinders cushioning of the headstock for automatic balancing during vertical motion.
 The multi speed spindle adopts a top quality German-built ZF helical planetary gearbox. Fully sealed immersion type lubrication, with an oil chiller and circulates coolant.
 The spindle is housed in a box type structure and rotates on high precision taper roller bearings allowing for all types of heavy duty cutting without vibration.
 The spindle and ball screws at all three axes are cooled by re-circulated oil which passes through an oil chiller.
