X23 is adapted with Germany H+L advanced Servo Hydraulic system, HPPC-30T. 30 tonnages provide more punching capacity, also the three pressure accumulators are capable of transform high/low resistance under high-speed punching capacity. Up to 450 hpm punching speed, controllable ram traverse for top/bottom dead center, favorable for processing with roller ball cutting, marking and some other special forming processing.
Servo motor with mechanical servo valve are replace the complex structure of the hydraulic servo valve, efficient reduce the maintenance cost. The excellent power-driven technology invalid energy consumption to a minimum.
HPPC-30T servo hydraulic system requires high energy only when tools in process of running throught metal sheet. Energy consumption very few in other stages. Slash area illustrates energy-saving in effect.
The table piece removed with the sheet in same speed and same direction. Protecting the sheet from friction by table.
This block raises while reposition. Protecting the sheet from scratch by reposition block.
