The HSP Series Tight Flask Molding line are self-contained units with integrated hydraulic system and electronic control used for small to medium casting production.

FEATURES:

  • 2-station molding machine with pattern turntable for alternate production of cope and drag molds
  • Average maximum mold rate of 70 molds/hr
  • Air-flow technology allows for consistent production of highly dimensional & accurate castings
  • Molding flask handling by hydraulic cylinder or electric motors on roller conveyors
  • Suitable for hand packing chills, open top feeder/riser setting or facing sand
  • Sand fill by hopper, discharge belt or batch hopper

Options

  • Fine Sand Slinger
  • Automatic Pattern Changer
  • Diaphragm Squeeze
  • Multi-ram Press
  • Pattern Heater



Download Here
